WATER PUMP

PRODUCT FEATURE
1, Wide input voltage range
100-240V,50160Hz
2,DC 24-60V output voltage
Human safe voltage, no risk of use
3,Constant pressure water supply
Adopt variable frequency technology,12,000r/min super high rotation speed, more precision pressure control
4, Adaptive function
Automatically identify the pipe pressure
Automatically regulate the starting pressure
5, Super long life span
S1 motor duty cycle, 30,000 hours of service life
6.Anti-freezing&pressure resistance
Small impeller, small pump body, higher hardness
7, Super quiet 20-30dB
Adopt permanent magnet motor and water cooling structure, don‘’t need cooling fan
8, Plug and play
9, Energy saving 70%
400W permanent magnet motor replaces 1100W traditional motor, bringing same performance
10,Max.suction is 9.5m, wider application range
11, Zero rust water
The fluid passage components are made of food grade plastic
12, Dual control system (pressure + flow switch)
Support stepless pressure regulation for pump with 0-100m head
13, Multiple protection
Water shortage protection, frequent start&stop protection, overcurrent&undervoltage protection,etc.
14, Timing fucntion, supply water for water tower
15, High pass rate of standard parts and high production efficiency
Customized mold for each part, no finishing, one corss screwdriver completes assembly and dissembly

WORKING CONDITION
Liquid temperature:0-100C
Ambient temperature:4-60°C
Insulation Class:H
Protection grade:lP 55
Duty cycle: S1
Input voltage:Single phase 100-240V,50/60Hz

APPLICATION
Well water lifting and water tower water filling
Living water supply and garden irrigation
Transfer clean water or non-corrosive liquid without solid particles and fibers
Pipeline pressure boosting and supporting equipment (solar energy water supply system, water heater, etc.
